15mm x 1/2" Male Taper Elbow - Compression Fittings - 20 Pack
Estimated delivery: in 1 working days
Order before the daily cut-off for this estimate.
Business days only. Weekend and post-cut-off orders are processed the next working day.Product information
The details you need before ordering
15mm x 1/2" Male Taper Elbow - Compression Fittings - 20 Pack details
This male taper elbow uses a compression connection to join 15mm copper tube to a 1/2 inch female threaded outlet at a right angle. Constructed from robust brass, the fitting is designed for reliable performance in both water and gas installations.
It is compatible with copper tubing manufactured to BS EN 1057 and is approved to BS EN 1254-2. WRAS approval ensures suitability for potable water systems. The elbow is built to withstand a maximum operating pressure of 16 bar and temperatures up to 110C, making it suitable for demanding environments in heating and water supply systems.
Supplied in a pack of 20, this fitting supports fast system building and ongoing maintenance. The compression connection allows for secure assembly and easy disassembly, providing flexibility across a range of installations in domestic or commercial settings. Guaranteed for 25 years.
Key features
- Manufactured to BS EN 1254,Compatible With Copper Tube Manufactured to BS EN 1057,WRAS Approved,Guaranteed for 25 years
Technical specifications
Unless stated, measurements are in millimetres (mm).
- Applications
- Gas,Water
- Colour
- Brass
- Connection Type
- Compression
- Finish
- Brass
- Manufacturer Guarantee
- 25 Years
- Material
- Brass
- Max Operating Pressure
- 16 Bar
- Max Operating Temperature
- 110C
- Pack Size
- 20
- Size Designation
- 15mm x 1/2"
- Standards
- BS EN 1254-2, BS EN 1057
- Style
- Elbow
- Type
- Adaptor
- WRAS Approved
- Yes
