15mm Gate Valve 1 Pack
Estimated delivery: in 1 working days
Order before the daily cut-off for this estimate.
Business days only. Weekend and post-cut-off orders are processed the next working day.Product information
The details you need before ordering
15mm Gate Valve 1 Pack details
This 15mm brass compression Gate Valve is engineered to provide reliable system isolation with minimum pressure loss. Manufactured to BS 5154 standards with compression ends to BS EN 1254-2, it features a non-rising stem design and comes with an aluminium handwheel for straightforward operation. The valve meets BS EN 12288 and BS EN 1057 standards, and carries full WRAS approval for assured compliance.
Gate Valves function by moving a gate mechanism up and down to control flow. When fully open, the unobstructed pathway delivers minimal pressure drop - making these valves ideal for applications where flow efficiency is critical. The gradual closing action effectively reduces water hammer risks, protecting your system from pressure spikes.
This valve operates across an extensive temperature range from -10°C to 170°C, offering versatility for various applications. Suitable for domestic, commercial, industrial and irrigation systems where complete isolation capability is required. Not designed for flow regulation or throttling applications.
Key features
- Manufactured to BS 5154
- Compression Ends to BS EN 1254-2
- Non Rising Stem
- WRAS Approved
What's in the box
- 1 x Gate Valve
Technical specifications
Unless stated, measurements are in millimetres (mm).
- Colour
- Brass
- Connection Type
- Compression
- Finish
- Brass
- Handle Type
- Handwheel
- Manufacturer Guarantee
- 5 Years
- Material
- Brass
- Max Operating Temperature
- 170C
- Min Operating Temperature
- -10C
- Pack Size
- 1
- Pressure Rating
- PN16
- Size Designation
- 15mm
- Standards
- BS EN 12288,BS EN 1254-2,BS EN 1057
- Stem Type
- Non-rising
- Type
- Handwheel
- WRAS Approved
- Yes
